Product Details

Blow Molding Thermoplastic Polyurethane Material

Key features：
- Polyester base
- Transparent pellet
- Hardness: 85A.90A
- Excellent operation
- Good Low Temperature Flexibility
- Suitable for isolation gown fabric (can reach AAMI Level 1/2)

Add to inquiry cart

Product Introduction

Application
Blowing and T-die for producing TPU film.

Physical Property

Product Number	Polyol	Hardness	Specific Gravity	Melting Point	Tensile Modulus @ 100% elongation	Tensile Modulus @ 300% elongation	Tensile Strength	Tear Strength
Product Number	Polyol	Shore A	g /cm³	℃	kgf/cm²	kgf/cm²	kgf/cm²	kgf/cm
TPUE-63-85AH8B5	Polyester	85±3A	1.2±0.05	145±5	50	80	250	70
TPUE-63-90AH8B5	Polyester	90±3A	1.2±0.05	155±5	70	110	300	100

Process Condition

METHOD	FEEDING ZONE(℃)	BARREL(℃)	SCR CHG’ER(℃)	Adapter(℃)	DIE(℃)
Blow Molding	180-190	180-190	180-190	180-185	180-185
T-Die	165-175	175-185	185-195	185-195	185-195
Notice: These values are based on the test of our present laboratory test specimens.

Taiwan PU Corporation is a professional blow molding thermoplastic polyurethane material manufacturer, blow molding thermoplastic polyurethane material producer. We supply high quality blow molding thermoplastic polyurethane material products, have an experienced technical team and offer the best price to blow molding thermoplastic polyurethane material.

Blowing thermoplastic polyurethane material is called TPU material for blowing, TPU material, blowing TPU material, thermoplastic polyurethane material for blowing, polyester based thermoplastic polyurethane for blowing. If blowing thermoplastic polyurethane material is needed, please contact us.
